24v 20a Under Bonnet DC Battery Charger

24v 20a Under Bonnet DC Battery Charger

Regular price $952.00
/
Tax included. Shipping calculated at checkout.

The REDARC BCDC2420 battery charger is a 24 Volt 20 Amp, three stage DC DC charger that operates from a vehicle input between 9 and 32 Volts DC. It is designed to charge any commonly used automotive 24V battery system to an optimal level with chemistry specific battery charging algorithms.

Fully potted and sealed, this DC-DC charger is perfect for under bonnet installations to withstand heat, water, dust and vibration to deliver perfect performance every time.

The BCDC2420 features a multi-stage charging algorithm, with a 24V charging output the DC to DC charger is perfectly suited to trucking applications such as charging battery banks for tailgate lifters and side curtains.

The BCDC2420 features a MPPT Solar Regulator, which means 12V solar panels can be used to charge your 24V auxiliary batteries. The MPPT Solar charging algorithm extracts the maximum available power from your solar panels at any given time.

Features:

  • Multi-Stage DC to DC Battery Charger
  • MPPT Solar Regulator
  • Start Battery Isolator
  • Fully sealed
  • No fan for super-quiet operation
  • Charges AGM, Gel, Calcium content, VRLA and Standard Lead Acid batteries
Specification
Battery Chemistry Standard Lead Acid, Calcium content, Gel, AGM or LiFePO4 type only
Continuous Rating 20A
Power Type - AC DC DC TO DC
Nominal Output Power 600W
Input Fuse Rating 60A (Not supplied) REDARC FK60 recommended
Solar Switch On Voltage 17.5V
Suitable For 12V Systems Yes
Suitable For 24V Systems Yes
Solar Input Voltage 9 - 32V
MPPT Solar Regulator Yes
Cabin/ Canopy Install Yes
No Load Current <100mA
Trailer Install Yes
Engine Bay Install Yes
Max. Charging Voltage 30.6V
Output Fuse Rating 40A (Not supplied) REDARC FK40 recommended
Operating Temperature -10°C to 79°C
Output Voltage 24V DC
Max. Rated Output Current 20A
Input Voltage 9 - 32V
Standby Current <8mA
Connector Type Bare wire
Weight 22 oz
Width 119mm
Height 38mm
Depth | Length 149mm
Warranty 2 Years
